Alpha & Omega RJ45 MIDI sender kit
Units in Stock: 1
£62.99 inc. tax
Bulk Buying Options
single: £62.99
2 up to 10: £65.99 per item
ALPHA α and OMEGA Ω
MINDBURNER active send and receive units
MIDI over CAT5
What do they do?
How do I connect them?
Can I use a mobile phone power bank?
Usually no. See POWER section in this link for details:
FAQs
Features:
MINDBURNER active send and receive units
MIDI over CAT5
What do they do?
MIDI will usually work fine up to 15 meters.
Over this, it's problematic.
These active devices transmit MIDI over long distance, 300M plus.
Over this, it's problematic.
These active devices transmit MIDI over long distance, 300M plus.
How do I connect them?
✫ Connect a MIDI master (keyboard etc) to the α device MIDI input.
✫ Add 5v DC power.
✫ Connect length of fully wired CAT5 network cable (not included) from α to Ω device.
✫ Connect MIDI slave device (module/etc) to the Ω device MIDI out.
✫ The master will now trigger the slave over distance.
✫ MIDI also works from Ω to α in the same manner, simultaneously.
How are they powered?
✫ Add 5v DC power.
✫ Connect length of fully wired CAT5 network cable (not included) from α to Ω device.
✫ Connect MIDI slave device (module/etc) to the Ω device MIDI out.
✫ The master will now trigger the slave over distance.
✫ MIDI also works from Ω to α in the same manner, simultaneously.
How are they powered?
Comes with 1 meter 2.1mm to USB lead to power from 5v USB
A decent 5v USB iphone type charger of 1A or more is ideal.
No USB? Can also use pretty much any 5v DC 'wallwart' type power transformer.
With a 2.1 mm positive tip plug.
A decent 5v USB iphone type charger of 1A or more is ideal.
No USB? Can also use pretty much any 5v DC 'wallwart' type power transformer.
With a 2.1 mm positive tip plug.
Can I use a mobile phone power bank?
Usually no. See POWER section in this link for details:
FAQs
Features:
✫ Active line driver technology
✫ Can be used in both directions simultaneously
✫ Overcomes MIDI distance
✫ Uses standard network cable CAT5/6
✫ Pair of devices included
✫ Reverse polarity protection
✫ Green DC Power LED
✫ DC Power is passed up CAT5, so only needs connected on one device
✫ MIDI input signal LED
✫ Very fast with no noticeable drop
✫ Passes all MIDI messages
✫ Dimensions 100W x60L x25H mm each board
✫ Power consumption 30mA each board
✫ Wiring is proprietary, so may not work with another manufacturer's CAT5 MIDI
✫ Network data cannot be sent using this device
✫ Used as a pair in either direction.
✫ Can be used in both directions simultaneously
✫ Overcomes MIDI distance
✫ Uses standard network cable CAT5/6
✫ Pair of devices included
✫ Reverse polarity protection
✫ Green DC Power LED
✫ DC Power is passed up CAT5, so only needs connected on one device
✫ MIDI input signal LED
✫ Very fast with no noticeable drop
✫ Passes all MIDI messages
✫ Dimensions 100W x60L x25H mm each board
✫ Power consumption 30mA each board
✫ Wiring is proprietary, so may not work with another manufacturer's CAT5 MIDI
✫ Network data cannot be sent using this device
✫ Used as a pair in either direction.
Product Code: RJ45_MIDI
Brand: Mindburner
Product Condition: New
